SwitchIt Privacy Glass
is an opaque white smart film, laminated between glass, that can instantly be changed into a clear glass window at the touch of a button.
These luxury glass panels provide easily-controllable, when-you-need-it privacy and security in both interior and exterior installations!
Glass & Panel Thickness/Size
SwitchIt Glass panels can be constructed using 5/32” glass panes or thicker, and can be multi laminated if required. Our standard, minimum thickness is total panel thickness of 3/8”. The largest sized SwitchIt GLass panel we currently produce is 71.5” x 120”.
Colors & Shapes
SwitchIt Glass can be manufactured using various colored glass; for example bronze, green, blue, or grey. The panels can be made curved, notched, or in any shape, and may also have holes cut out.
Clear Edge
All switchable privacy panels will have a surrounding clear edge of approximately 3/16”. This will be hidden when fully framed. In semi-framed or butt-jointed panels, the clear edge will be visible.
Glass Location
Consideration must be given to where, within a building, the SwitchIt Glass panels are to be used. In some locations building codes may require toughened laminated glass be used, and/or double glazed.
SwitchIt Glass used on external walls: Sometimes extreme climatic conditions may require that the panels be double glazed units and incorporate Low-E glass.
Framing
SwitchIt Glass panels can be framed into most standard framing systems for single or double glazing. The only considerations are: Our minimum panel thickness is 3/8”. However, most orders are accommodated by 9/16” OA thickness.
Installation
SwitchIt Glass panels must be installed by qualified glaziers. A qualified electrician is also required for the wiring-in of the product. Failure to meet either of the above-mentioned stipulations will void the SwithIt Glass Warranty.
Glass Types
SwitchIt Glass panels can be constructed using the following glass types:
- Annealed (Float)
- Toughened/tempered
- Impact-resistant
- Low Emissivity
- Low Iron (Starphire, Optiwhite)
- Colored
- Operable Wall Systems
Clarity
There is an inherent slight haze in switchable privacy glass in its clear “on” state; therefore, it is important to consider the ambient luminescence and lighting near your SwitchIt Glass panel(s) in order to create optimal display conditions (in either “on” or “off” state).
Wet Location
SwitchIt Glass panels that are to be installed in wet areas such as bathrooms or shower cabinets will need to be sealed, the edges impervious to water, and fully framed. In many wet situations, standard warranty is reliant upon manufacturers approval of installation.
